1. Metallized Polyester
Film Capacitor ( ME
type )
2. Metallized Polypropylene Film
Capacitor ( MP
type )
3. Polypropylene Film + AL
Foil Capacitor ( NP
type )
4. Non-Inductive Polyester Film
Capacitor ( NE
type )
5. Polyester Film
Capacitor/Mylar ( MH
type )
6. Polyester + Polypropylen Film
capacitor ( PD
type )
7. Polypropylene Film
Capacitor ( PP
type
)
|
TYPE
|
Configuration
|
Working
Voltage |
Range(uF)
|
Temperature
Range (℃) |
| ME | Metallized Polyester
Film | 100-630V | 0.01 -
6.8 | -40 ˜
+85
|
| ME(AC) | Metallized Polyester
Film | 125-400V | 0.01 -
3.3 | -40 ˜
+85
|
| MP | Metallized Polypropylene
Film | 100-630V | 0.047 -
1.2 | -40 ˜
+85
|
| NP | Polypropylene Film + Al
Foil | 100-630V | 0.001 -
0.39 | -40 ˜
+85
|
| NP | Polypropylene Film + Al
Foil | 800-1600V | 0.001 -
0.068 | -40 ˜
+85
|
| NE | Polyester Film + Al
Foil | 100-630V | 0.001 -
0.39 | -40 ˜
+85
|
| MH | Polyester Film + Al
Foil | 50-400V | 0.001 -
0.47 | -40 ˜
+85
|
| PD | Polyester Film
Polypropylene+Al Foil | 50-100V | 0.001 -
0.47 | -40 ˜
+85
|
| PP | Polypropylene Film+Al
Foil | 50-400V | 0.00033 -
0.1 | -40 ˜
+85
|
 | |||||||||||||||||||||||||
 |
| ||||||||||||||||||||||||
